3 in 1 DIY Woodworking Dowel Drilling Gauge Drilling Aid Dowel Gauge Drilling Template Guide Kit 6/8/10mm
Return&refund policy
Eligible items are covered by return and refund support. If the item does not arrive or is not as described, the buyer can request help.
Security & Privacy
Safe payments: We do not share your personal details with any third parties without your consent.
Secure personal details: We protect your privacy and keep your personal details safe and secure.
AI offer for your market
A curated pick based on category, shipping route, delivery speed and popularity in your selected market.
Why this product fits your market
- • Estimated delivery: 7.
- • Recommendations focus on this product category and your market availability.
Product specifications
Detailed product description
This product is shown with available options, market-specific pricing and verified specifications.
- Brand: CNCEST
- Package size: 34 × 22 × 6 cm
- Package weight: 1.75 kg
- Rating: 0.0 / 5
- Color: Silve
Before adding to cart, choose an available option and check the quantity.
Product Description
Our punch locator tool, using high-quality materials such as aluminum alloy and nitride tool steel, is corrosion-resistant, wear-resistant, and high-strength. It is equipped with 9 threaded drill sleeves, and three 6/8/10mm size drill bits, together with a clear metric scale, making it so precise and practical that it is a great choice for DIY and woodworking enthusiasts.
Key Features
Premium Material—— This punch locator consists of an aluminum alloy drill guide and nitride tool steel drill housing, together with an anodic oxidation treatment, making it corrosion-resistant, wear-resistant, and high-strength.
Exquisite Processes—— The rigorous and precise processes including CNC computer engraving and molding ensure high precision and long service life.
Precise Positioning&Drilling—— The 6/8/10mm threaded drill sleeves, strong magnetic sheet&shim, and two clamping methods (horizontal and vertical), allow you to easily and accurately find the center and drill holes of the corresponding size.
Multiple Functions—— This punch locator can be used for opening eccentric wheel holes, rubber particle holes of connecting rods, log mortise holes, and L-type&T-type three-in-one splicing, which are optional and practical.
High Portability—— The punch locator tool weighs only 4.14 lbs, which is convenient to carry and store.
Adjustable Design—— The drill guide rails are adjustable and the eccentric wheel hole position is precisely adjusted according to the length of the connecting rod to easily meet your various drilling requirements.
Protective Package—— To prevent the product from being damaged and bumped during transportation, we packed it with pearl-cotton buffer to protect your products to the maximum extent possible.
Specifications
Model: MD590
Color: Silver
Drill Guide Material: Aluminum Alloy 6061
Drill Housing Material: Nitride Tool Steel
Surface Treatment: Anodic Oxidation
Process: CNC Computer Engraving and Molding
Style: Practical
Power Source: Hand Powered
Side Hole Accuracy: ＜0.5mm/0.02inch
Clamping Board Thickness: ＜90mm/3.5inch
Connection Rod Length: About 32mm/1.26inch
Drilling Thickness: 10-180mm/0.4-7.08inch
Side Hole Diameter: 15mm/0.59inch
Positive Hole Size: 6mm/0.23inch, 8mm/0.315inch, 10mm/0.4inch
Slider Stroke: 5-90mm/0.2-3.54inch
Side Hole Stroke: 23-43mm/0.9-1.69inch
Guide Rail Length: 30cm/11.8inch
Clamp Plate Height: 88mm/3.46inch
Motherboard Size(L*W): 173*88mm/6.8*3.46inch
Package Size: 34*22*6cm/13.38*8.66*2.36inch
Net Weight: 1.6kg/3.5lbs
Gross Weight: 1.88kg/4.14lbs
Package Included
1* Punch Locator
3* 6mm Drill Sleeves
3* 8mm Drill Sleeves
3* 10mm Drill Sleeves
1* 6mm Border Ring
1* 8mm Border Ring
2* 10mm Border Rings
1* 6mm Drill Bit
1* 8mm Drill Bit
1* 10mm Drill Bit
2* Star Screws
1* 15mm Hole Opener
1* Half-moon Key
1* Clamp Plate
1* Slider Set
1* Motherboard
2* Wrenches
1* Chinese&English Manual
Other Accessories for Assembly.
How to Use
1.Measure the thickness of the plate to be punched.
2.Adjust the position of the eccentric drill sleeve according to the specification of the connecting rod.
3.Adjust the slider position scale, and the scale value is half of the plate thickness. If the corresponding scale cannot be aligned, add a shim of the corresponding size.
Details
Clear Scale: The clear and precise metric scale makes it easy to find the center of a board’s edge every time without tedious trial and adjustments.
Parallel Arms: Two precisely machined parallel arms can be quickly adjusted to the stock thickness, and then the central bar is placed in the center of the material, making the operation easier.
Special Rail: It is not necessary to use locking pliers to clamp the board when punching the side with the equipped special rail.
Application:It is suitable for all kinds of furniture such as doors, windows, cabinets, tables, etc. And it is an ideal choice for clamping boards with a thickness of less than 3.5".
Product detail image display
Notes
1.Since the slider slides 2mm each time, it can only be aligned with the center of the 10, 14, 18, 22mm, etc. thick plates. If the thickness of the plate is not suitable, it will not be able to align with the center to punch holes without adding a shim.
2.Please control the drilling depth by setting the border ring.
4.Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
