4K Microscope For Electronics 48MP Digital Microscope Camera Optional 1-150x Lens LED Light Foldable Bracket Phone Pcb Soldering
Return&refund policy
Eligible items are covered by return and refund support. If the item does not arrive or is not as described, the buyer can request help.
Security & Privacy
Safe payments: We do not share your personal details with any third parties without your consent.
Secure personal details: We protect your privacy and keep your personal details safe and secure.
AI offer for your market
A curated pick based on category, shipping route, delivery speed and popularity in your selected market.
Why this product fits your market
- • Estimated delivery: 5.
- • Strong customer signal: 4.8★ from 120 reviews.
- • Recommendations focus on this product category and your market availability.
Product specifications
Detailed product description
This product is shown with available options, market-specific pricing and verified specifications.
- Brand: YIZHAN
- Sales: 232
- Package size: 47 × 21 × 8 cm
- Package weight: 1.35 kg
- Rating: 4.8 / 5
Before adding to cart, choose an available option and check the quantity.
Maximum working distance of lens 100CM!
Be sure to use the microscope in a bright environment, otherwise the image will not be clear.
Product description
48MP HDMI USB 4K Camera
Model: Camera with HDMI USB2.0 two output
Image sensor: 48 megapixel Sony sensor
Frame rate: 1920*1080 60F/S @ HDMI output
Video save Movie size:4K(25fps) 2K(30fps) 1080P(60fps) 720P(60fps)(Note: If you need to record 4K or 2K video, you need to use the SDHC class10 TF card.)
Housing: All metal
Support:C-Mount lens
Digital magnification: 5 times digital zoom
White balance: Auto/manual
Cross cursor: Support multi-color, size adjustable
TF card interface: Max 32G
video format:MOV
HDMI interface: HDMI/USB output
Image: 48M 8000X6000/38M 7168X5376/26M 5888X4416/20M 5120X3840/16M 4608X3456
Language:Chinese/English
Mirroring: Support
Frequency:50Hz/60Hz
Monitor:16:9/16:10/4:3
Grid line: 15 Horizontal line, 15 Vertical line, Central scale line,Custom colors,Size
Power supply:5-12V 1A
48MP ALL 4K HDMI USB Camera
Pixel size:2.9µm × 2.9µm
HDMI output: 60FPS
Lens interface:C/CS
exposure:Automatic / manual
exposure compensatio:support
white balance:Automatic / manual, support for RGB adjustable
memory Max. support is 64GB
input voltage:DC: 5V
lineation 16 lines, with adjustable color, thickness, and position
centre line:support
telecontroller:Support for the remote control operation
net weight:150g
rough weight:350g
product size:66*66*49mm
packing measurement:145*130*70mm
1X-150X Zoom C-mount Lens
Working distance: 50mm-1000mm
zoom ratios: 1: 15
Magnification Power by 0.15- 2X (about 1 - 150X on the display)
view field of Max multiple: 4.2mm*2.4mm
view field of Min multiple: 130mm*70mm
Size: 30mm(diameter) * 99mm(length)
Weight: 195g
56 bright white LED bulbs：
100,000 hours of life
Intense and focused shadow-free illumination
The brightness of 0-100%Adjustable,high brightness
Variable intensity control
Power input: 90-260V, 50-60HZ
Suit for the dia of the lens: 30mm-63mm
Working distance:400mm
Adjustable bracket ：
size: 340mm+320mm
Maximum thickness of bracket installation: 50mm
It is recommended that when the working distance exceeds 40cm, please use a work desk lamp to fill in the light.
List of packing：
FUll Set：
1 x Microscope Camera
1 x Power Adapter
