High Precision Static Torque Sensor 0-2000Nm Flange Type Square Drive Torque Transducer for Bolt Tightening Detection
Return&refund policy
Eligible items are covered by return and refund support. If the item does not arrive or is not as described, the buyer can request help.
Security & Privacy
Safe payments: We do not share your personal details with any third parties without your consent.
Secure personal details: We protect your privacy and keep your personal details safe and secure.
AI offer for your market
A curated pick based on category, shipping route, delivery speed and popularity in your selected market.
Why this product fits your market
- • Estimated delivery: 7.
- • Strong customer signal: 5.0★ from 10 reviews.
- • Recommendations focus on this product category and your market availability.
Product specifications
Detailed product description
This product is shown with available options, market-specific pricing and verified specifications.
- Brand: ZHIZHONGYIQI
- Sales: 31
- Package size: 15 × 6 × 5 cm
- Package weight: 0.9 kg
- Rating: 5.0 / 5
Before adding to cart, choose an available option and check the quantity.
参数名称 (Name / Название / Nombre)
单位 (Unit)
参数值 (Value)
量程 / Rated Capacity / Диапазон / Alcance
N.m
2 ~ 2000
灵敏度 / Sensitivity / Чувствительность / Sensibilidad
mV/V
2.0 ± 0.1
综合精度 / Total Accuracy / Общая точность / Precisión
%F.S
0.1
蠕变 / Creep / Ползучесть / Fluencia
%F.S / 30min
± 0.05
非线性 / Non-linearity / Нелинейность / No linealidad
± 0.1
滞后误差 / Hysteresis Error / Гистерезис / Histéresis
重复性误差 / Repeatability / Повторяемость / Repetibilidad
零点温度系数 / Zero Temp / ТКП / Coeficiente cero
%F.S / 10°C
输出温度系数 / Output Temp / ТКЧ / Coeficiente salida
одное сопр / Resistencia ent
Ohm
725 ± 25
одное сопр / Resistencia sal
700 ± 1
绝缘电阻 / Insulation / Сопротивление изоляции / Resis. aislat
MOhm
激励电压 / Excitation / Напряжение питания / Voltaje excit
VDC
9 ~ 15
工作温度范围 / Operating Temp / Температура / Temp. trabajo
°C
20 ~ +70
150
密封等级 / IP Rating / Класс защиты / Grado protección
/
IP66
材质 / Material / Материал / Material
Alloy Steel / Лег.сталь / Acero
