DWIN 7 Inch LCD Module 800*480 RS232/TTL HMI Commercial Touch Panel Screen Smart UART TFT Display DMG80480C070-04W
Return&refund policy
Eligible items are covered by return and refund support. If the item does not arrive or is not as described, the buyer can request help.
Security & Privacy
Safe payments: We do not share your personal details with any third parties without your consent.
Secure personal details: We protect your privacy and keep your personal details safe and secure.
AI offer for your market
A curated pick based on category, shipping route, delivery speed and popularity in your selected market.
Why this product fits your market
- • Estimated delivery: 7.
- • Strong customer signal: 4.9★ from 42 reviews.
- • Recommendations focus on this product category and your market availability.
Product specifications
Detailed product description
This product is shown with available options, market-specific pricing and verified specifications.
- Brand: DWIN
- Sales: 126
- Package size: 25 × 20 × 8 cm
- Package weight: 0.5 kg
- Rating: 4.9 / 5
Before adding to cart, choose an available option and check the quantity.
Features
Specifications
Display parameters
Model
DMG80480C070_04WTC: Capacitive touch
DMG80480C070_04WTR: Resistive touch
DMG80480C070_04WN: No touch
LCD Type
TV-TN, TFT LCD
Viewing Angle
TV viewing angle, 70°/70°/40°/30° (L/R/U/D)
Resolution
800×480 pixels (support 0°/90°/180°/270°)
Color
18-bit 6R6G6B
Active Area (A.A.)
154.08mm (W)×85.92mm (H)
Backlight Mode
LED
Backlight Service Life
>20000 hours (Time of the brightness decaying to 50% on the condition of continuous working with the maximum brightness)
Brightness
DMG80480C070_04WTC: 200nit
DMG80480C070_04WTR: 200nit
DMG80480C070_04WN: 250nit
Brightness Control
0~100 grade (When the brightness is adjusted to 1%~30% of the maximum brightness, flickering may occur and is not recommended to use in this range)
Serial interface parameters
Mode
UART2: ON=TTL/CMOS;OFF=RS232
UART4: ON=TTL/CMOS;OFF=RS232 (Only available after OS configuration)
Voltage Level
Test Condition
Min
Typ
Max
Unit
Output 1, Iout = 1mA
3.0
3.3
V
Output 0, Iout = -1mA
0
0.3
Input 1, Iin = 1mA
2.4
5.0
Input 0, Iin = -1mA
0.5
Baud Rate
3150~3225600bps, typical value of 115200bps
Data Format
UART2: N81
UART4: N81/E81/O81/N82, 4 modes (OS configuration)
Interface Cable
10Pin_1.0mm
Electrical specifications
Rated Power
Operating Voltage
4.5~5.5V, typical value of 5V
Operating Current
510mA
VCC=5V, max backlight
170mA
VCC=5V, backlight off
Recommended power supply: 5V 1A DC
Operating environment
Operating Temperature
10℃~60℃(5V @ 60% RH)
Storage Temperature
