KP184 Single-channel DC Electronic Load Tester Battery Capacity Tester 4 Load Modes Different Test Functions 150V 0-400W 0-40A
Return&refund policy
Eligible items are covered by return and refund support. If the item does not arrive or is not as described, the buyer can request help.
Security & Privacy
Safe payments: We do not share your personal details with any third parties without your consent.
Secure personal details: We protect your privacy and keep your personal details safe and secure.
AI offer for your market
A curated pick based on category, shipping route, delivery speed and popularity in your selected market.
Why this product fits your market
- • Estimated delivery: 7.
- • Strong customer signal: 5.0★ from 7 reviews.
- • Recommendations focus on this product category and your market availability.
Product specifications
Detailed product description
This product is shown with available options, market-specific pricing and verified specifications.
- Brand: NONE
- Sales: 9
- Package size: 39 × 28 × 17 cm
- Package weight: 4.5 kg
- Rating: 5.0 / 5
Before adding to cart, choose an available option and check the quantity.
Description
The KP184 single-channel DC electronic load tester has four load modes (CC, CV, CW, and CR) with good heat dissipation. The multiple protections and different test functions can meet your testing demands while ensuring the machine's safe use. The performance and function are unmatched by traditional slide wire resistors. If it is used for related industries, it could enhance productivity and reduce costs.
Specification
Model: KP184
Color: Blue
Shape: Rectangular
Style: Modern
Power Type: Plug-in
Plug: EU Standard/US Standard
Power Input
Voltage: AC 110V/220V±10%, 50±2Hz
Power Consumption: < 20 W
Load Input
Load Voltage: DC 1 -150 V
Load Current: 0-40A
Load Power: 0-400W
Measurement Accuracy
Current: ±0.05%+5mA
Voltage: ±0.05%+5mV
Control Precision
Communication Method: RS232/RS485
Protection
Over Voltage (OV): Greater Than 152V Off Load
Over Temperature (OT): 85℃/185℉
Over Power (OP): Single Channel 410W
Power Input Fuse: 0.5A
Ambient Temperature Range: 0～500℃/0~932℉
Ambient Humidity Range: 10~90%RH
DC Input Terminal to Chassis Withstand Voltage: ±500VDC
DC Input to Chassis Insulation Resistance: >20MΩ, 500VDC
AC Input to Chassis Insulation Resistance: >20MΩ, 500VDC
Weight: 4.5kg/9.9lbs
Packing Size: 38.5*16*27cm/15*6*10inch
Product Size: 30*9*18cm/11*3*7inch
Package Included
1* KP184 Single Channel DC Electronic Load Tester
1* Power Cord
1* Remote Compensation Terminal
2* Positive and Negative Test Terminals
2* Test Cables
1* English User Manual
Key Features
4 Load Modes: The four load modes including CC, CV, CW, and CR that can be operated synchronously online can meet your testing demands.
Different Test Functions: The functions of voltage far-end measuring, auto testing, 10KHz dynamic testing, battery capacity testing, battery internal resistance testing, and overcurrent protection point/ time testing can meet your testing demands.
Digital Control Mode: The digital control mode makes it have high precision and good stability to ensure accurate test results.
Switchable Voltage: The voltage can be switched between AC110V and AC220V, allowing this machine to be used under different voltages.
Easy to Use:The clear interface and one-button switch make operation easier.
Excellent Heat Dissipation: The heat dissipation holes on both sides can dissipate heat in time to prolong the machine's service life while ensuring high power density.
Multiple Protections: Over voltage protection, over current protection, over power protection, over temperature protection, and input positive and negative transposition protection can ensure your safe use.
Application
It can be widely applied to product testing and aging in LED lighting, power source, charger, and accumulator.
Notes
1.Please read the manual completely before installation and use, and pay particular attention to the safety instructions included.
2.Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before ordering.
