1P 2P 3P 4P DZ47 3A-125A AC 230V 400V C Type Mini Circuit Breaker MCB Short Overload Protector Din Rail Mount Breaking Capacity
Return&refund policy
Eligible items are covered by return and refund support. If the item does not arrive or is not as described, the buyer can request help.
Security & Privacy
Safe payments: We do not share your personal details with any third parties without your consent.
Secure personal details: We protect your privacy and keep your personal details safe and secure.
AI offer for your market
A curated pick based on category, shipping route, delivery speed and popularity in your selected market.
Why this product fits your market
- • Estimated delivery: 7.
- • Strong customer signal: 5.0★ from 29 reviews.
- • Recommendations focus on this product category and your market availability.
Product specifications
Detailed product description
This product is shown with available options, market-specific pricing and verified specifications.
- Brand: EARU
- Sales: 103
- Package size: 7 × 8 × 8 cm
- Package weight: 0.6 kg
- Rating: 5.0 / 5
Before adding to cart, choose an available option and check the quantity.
We can offer OEM service to manfacture the circuit breaker with your logo
Application
C45N series circuit breaker is used in lighting distribution system or motor distribution system for protecting overload and short-circuit in the system. The product is novel in structure, light in weight, reliable and excellent in performance. It has high breaking capacity, can trip quickly and it's installation uses with guide, it's case and items are adopted with high fire-retartant and shockproof plastics. The product, with long life, is mainly used in AC 50Hz/60Hz, single-pole 240V or two, three, four-pole 415V circuit for overload and short-circuit protection as well as for unfrequent on-and-off switching electric equipment and lighting circuit in normal case.IEC60898-1
Specificaatios
Poles:1P,2P,3P,4P
Rated Current (In): 3A-125A
Rated Voltage (Ue):1P:230/400V~;2P-4P:400V of 1P:240/415V~;2P-4P:415V
Working Frequency:50/60Hz
Tripping Curves:C
Breaking Capacity:3A-63A 6kA / 80A-125A 10kA
Mechanical Life:20000 time
Electrical Life:6000 time
As Per Instantaneous Release Type:C type (5ln~10ln)
