For Honda CBF 1000 F FA CBF1000 CBF 1000F 1000FA Motorcycle Accessories Gear Indicator Ecu Speed Gear Display Meter Waterproof

For Honda CB250F(with digital trip/odo) 2015

For Honda CB300F

For Honda CB400SF

For Honda CB400X

For Honda CB400F

For Honda CB500F

For Honda CB500X

For Honda CB600F Hornet

For Honda CB650F

For Honda CB1000R

For Handa CBR1000RR

For Honda CB1100 (non-ABS)

For Honda CB1100 (ABS)

For Honda CB1300 S/F

For Honda CBF600

For Honda CBF1000 F/FA

For Honda CBR250 2015

For Honda CBR300R

For Honda CBR400R

For Honda CBR500R

For Honda CBR600F

For Honda CBR600RR

For Honda CBR650F

For Honda CMX300 Rebel 2017

For Honda CMX500 2017

For Honda CRF250L/M All Years

For Honda Crossrunner All Years

For Honda CTX700 (w/o DTC)

For Honda Fury

For Honda Interstate

For Honda NC400X

For Honda NC700 S/X

For Honda NC750 S/X

For Honda NT700V Deauville

For Honda Sabre

For Honda Stateline

For Honda VFR800 interceptor

For Honda VFR800X All Years

For Honda VT400 (FI model)

For Honda VT750C (FI model)

For Honda VT750S (FI model)

For Honda VT1300 (All)

For Honda VTX1800

For Honda XL125V Varadero

For Honda XL700V Transalp (non-ABS)

For Honda XL700V Transalp (ABS)

For Honda XL1000V Varadero

For Honda TRX ATVs (FI model) All Years

For Honda CB300R

For Honda CTX1300

For Honda ST1300

For Honda VTR250

Condition:100% Brand New

Color of Light Source:Red/Blue/green/white/orange

Item Name:Speed Gear Display Indicator

Size:4cm*4cm*4cm/1.57inch*1.57inch*1.57inch

Shows current gear number

Indicates current gear from 1 to max of 6. as well as a neutral indicator.

Detects the current gear faster than other gear indicators that use speedometer/tachometer signal.

Display can be mounted anywhere

Find the RED,4-pole male diagnostic connector(DLC), usually near the ECU box,It may have a removable cap and may be partially covered by black tape.

You need to setup the module after installation. When ignition is turned on, the display counts backwards (6 to 1) indicating that the memory is clear.

Raise the rear wheel off the ground by using a stand, and start the engine in Neutral. (If you do not have a stand, you may setup the unit while riding. Find a long, straight road with light traffic.)

the screen displays L, indicating that learning is started.

The screen displays L, select first gear, release the clutch, and keep the speed higher than the idle speed.

The display will flash "1";. Continue to maintain the first gear, accelerate. When the device is learning a gear, the display flashes faster.

When the display shows n, relax the handlebar accelerator.When the gear indicator changes from "n" to "2", the motorcycle immediately shifts into "2" gear, then continue to to refuel and accelerate slowly.

When the display shows n again, relax the handlebar accelerator again.When the gear indicator changes from "n" to "3",the motorcycle immediately shifts into "3" gear, then continue to refuel and accelerate slowly.

Repeat this process until all gears are thought.

In the highest gear, when learning sixth gear, the display will flash 6, accelerate until o is displayed, and then 6 will stay on and stop flashing. Indicates that the configuration is complete.

The unit is programmed and should indicate the gears correctly.

Now, when ignition is turned on, the display counts forward (1 to 6) indicating that it is fully functional.

If some gears are not indicated correctly, reset the unit and set it up again.If you change your gearing (install new front or rear sprocket),or you install a speedometer (or other speedometer calibrator),probably you will have to reset it and set it up again. Cut off the power of the unit 6 times in a row,while the display is counting up and shows3,4 or 5. You can power on/off the display by turning the ignition key on/off.On the next power up,the display will count backwards(6 to 1). The memory is clear now and you can perform the Setup procedure.
