27Pcs /16pcs/10pcs BGA general template Universal Direct Heated Stencils For SMT SMD Chip Rpair and easy support
Return&refund policy
Eligible items are covered by return and refund support. If the item does not arrive or is not as described, the buyer can request help.
Security & Privacy
Safe payments: We do not share your personal details with any third parties without your consent.
Secure personal details: We protect your privacy and keep your personal details safe and secure.
AI offer for your market
A curated pick based on category, shipping route, delivery speed and popularity in your selected market.
Why this product fits your market
- • Estimated delivery: 3.
- • Strong customer signal: 5.0★ from 26 reviews.
- • Recommendations focus on this product category and your market availability.
Product specifications
Detailed product description
This product is shown with available options, market-specific pricing and verified specifications.
- Brand: NONE
- Sales: 63
- Package size: 10 × 10 × 10 cm
- Package weight: 0.05 kg
- Rating: 5.0 / 5
Before adding to cart, choose an available option and check the quantity.
Features
Made of imported stainless steel plate. Good stencil thickness.
Can be directly heated by air gun, steel mesh is not easy to deformation by heat.
Each set of 27 pieces. Basically covers the current common BGA chip.
Steel mesh area and BGA chip area matching, can reduce the waste of solder ball.
But for chip that solder balls uneven arranged or has different distance, please consider buying.
Universal direct heat BGA stencils for notebooks, desktops, XBOX, North and communications motherboards and other graphics cards and other types of BGA chip
10pcs stencils are as follows
1pc:0.3 universal stencil(P=0.58mm)
1pc:0.35 universal stencil(P=0.65mm)
1pc:0.4 universal stencil(P=0.7mm)
1pc:0.45 universal stencil(P=0.78mm)
1pc:0.5 universal stencil(P=0.8mm)
1pc:0.55 universal stencil(P=1.02mm)
3pc:0.6 universal stencil(P=0.9mm,P=1.0mm,P=1.1mm)
1pc:0.76 universal stencil(P=1.27mm)
16pcs stencils are as follows
1pc:0.35 universal stencil(P=0.6mm)
1pc:0.5 universal stencil(P=0.78mm)
2pc:0.6 universal stencil(P=0.9mm,P=1.1mm)
40mm*40mm
4pcs:0.6 universal stencil(P=0.99mm)
24mm*24mm 27mm*27mm 30mm*30mm 41mm*41mm
4pcs:0.76 universal stencil(P=1.27mm)
30mm*30mm 33mm*33mm 34mm*34mm 41mm*41mm
27pcs stencils are as follows
1pc:0.25 universal stencil(P=0.5mm)
1pc:0.3 universal stencil(P=0.5mm)
1pc:0.5 universal stencil(P=0.81mm)
1pc:0.65 universal stencil(P=1.0mm)
1pc:1.0 universal stencil(P=1.5mm)
5pcs:0.6 universal stencil(P=0.99mm)
24mm*24mm 27mm*27mm 30mm*30mm 33mm*33mm 41mm*41mm
5pcs:0.76 universal stencil(P=1.27mm)
30mm*30mm 33mm*33mm 34mm*34mm 37mm*37mm 41mm*41mm
Note
Better solder ball has normal content of tin and silver. Melting point is normal.
Direct heat with air gun, adjust the air gun temperature. No need too high temperature, otherwise cause deformation.
