ADS8688 SAR/ADC Datenerfassungsmodul AD 16-Bit 500 kSPS Single/Bipolar Input 8-Kanal Analog-Digital-Konvertierungsplatine

Produktbeschreibung

ADS8688 is an 8-channel integrated data acquisition system based on 16 bit successive approximation (SAR) mode A digital converter (ADC) can operate with a throughput of up to 500kSPS. These devices provide Integrated analog front-end circuits for each input channel (overvoltage protection up to 20V) support automatic and Manual 8-channel multiplexer with two scanning modes and low temperature drift chip 4.096V Reference voltage. When using a 5V single analog power supply, all input channels on the device can be supported Holding 10.24V, 5.12V and soil Actual bipolar input range of 2.56V and 0V to Single pole input range from 10.24V and 0V to 5.1 2V. Analog front-end within all input ranges The gains are precisely tuned to ensure high DC accuracy| The selection of input range can be done through the software
The selection of input ranges for each channel is independent of each other through programming. This device provides A constant resistive input impedance of 1 MO (regardless of the selected input range).
Module model: ADS8688
Module type: analog to digital conversion module
Module power supply: 5V
Static power consumption

Produktdetails in Bildern

Produkteigenschaften

Markenname

EC Buying

Ursprung

CN (Herkunft)

Hochbetriebenes Chemikalienunternehmen

Keine

Zustand

Neu

Typ

SPANNUNGSREGELER

Versorgungsspannung

5V

Verlustleistung

low

ist kundenspezifisch

Ja

Betriebstemperatur

40℃-85℃

Anwendung

Computer

Paket

Module

Smart Electronics Experiment

Switch And Sensor For Arduino STM32
