DC Power Fuse Distribution Strip Modul Klemmenblock 6 Positionen erweiterbar

Produktbeschreibung

DC Power Fuse Distribution Strip Module Terminal block (6 Position Expandable)
Working Voltage: DC 0 to 32V.
Maximum Total Input Current: 30 Amps.
6 Channels output, each channel maximum output current 3 Amps (Factory-installed fuse value 5 Amps, you can replace the fuse to support up to 10 Amps.)
Fuse holders for Medium Blade ATO/ATC Fuse, the fuse can be removed and replaced very easily. With fuse fail indication function, when you connected load and the fuse has blown or has been unplugged, green indication LED will turn on.
FR-4 fiberglass dual copper layers PCB.
Input Terminals: pitch 7.62mm/0.3", maximum current 30 Amps for per position, wire size 26~10 AWG, stripping length 8mm, Metric M3 slotted screw. Support power supply expansion connect to other modules.
Output Terminals: pitch 5.08mm/0.2", wire size 26~12 AWG, stripping length 7mm, Metric M2.5 slotted screw.
Shipping
1. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility.
2. Please check with your country’s customs office to determine what these additional costs will be prior to bidding/buying.
Return Policy
If the item is defective, please contact us within 30 days, you can choice money back or item exchange.
Contact us
Any questions, please feel free to contact us. due to time zone differences, we may not immediately answer you, but we promise to answer you within 24 hours.

Produktdetails in Bildern

Produkteigenschaften

Markenname

NONE

Spannung

220 v

Ist drahtlose Funktionalität enthalten?

Nein

Ursprung

CN (Herkunft)

Ist eine Batterie im Lieferumfang enthalten?

Nein

Hochbetriebenes Chemikalienunternehmen

Keine

EU LVD-Spannung

Niederspannung: Unter 50 VAC oder 75 VDC

Modellnummer

DCFM-1037-A1

Zertifizierung

UL

Distribution Strip Module

6 Position

Working Voltage

DC 0 to 32V

Maximum Total Input Current

30 Amps
