Rauschsensor, hochpräzises Dezibelmessgerät, RS485, 0–5 V, 0–10 V, 4–20 mA, 4 G-Ausgang, On-Board-Rauschsender, TTL-Modul

Produktbeschreibung

Noise Sensor High Accuracy Decibel Meter RS485 0-5V 0-10V 4-20MA 4G Output On-Board Noise Transmitter TTL Module
Noise transmitter
(Type 485)
1.1 product overview
The noise sensor is widely used in industrial field noise testing, can be widely used in warehouses, computer rooms, production workshops, archives, libraries, schools, shopping malls, smart home, building control, airports, railway stations and other fields.
1.2 functional characteristics
This product uses high sensitivity capacitive microphone, signal stability, high accuracy. The utility model has the advantages of wide measuring range, good linearity, convenient use, convenient installation, long transmission distance, etc.
The product can also be used in a combination of multiple sensors in a 485 bus, in theory a bus can be 254485 sensors, the other end with a 485 interface PLC, 485 interface chip connected with the MCU, or use USB to 485 can be connected to the computer, the use of my company's sensor configuration tools for configuration and testing (use the configuration software can only be connected to one device).
(Analog volume)
The noise sensor is widely used in the field of industrial noise measurement, can be widely used in warehouses, computer rooms, production workshops, archives, libraries, schools, shopping malls, smart home, building control, airports, railway stations and other fields.
This product uses the high sensitivity pickup, the signal is stable, the precision is high. The utility model has the advantages of wide measuring range, good linearity, convenient use, convenient installation, long transmission distance, etc..
When the system needs to access an analog version of the sensor, you only need to power the device, while the analog output line into the MCU or PLC DI interface, at the same time, according to the conversion relations of the corresponding acquisition program can be written.

Produktdetails in Bildern

Produkteigenschaften

Markenname

NONE

Hochbetriebenes Chemikalienunternehmen

Keine

Ursprung

CN (Herkunft)

Ausgabe

Analoger SENSOR

Theorie

Ultraschallsensor

Typ

TONSENSOR

Benutzen

VIBRATIONSSENSOR

Material

Mischung

isCustomized

Yes

Theory

Ultrasonic Sensor

Usage

Vibration Sensor

Material

Mixture

Type

Sound Sensor

Output

Analog Sensor

Origin

Mainland China
