integrierte Schaltung

1-5 Stück Rd-03 Rd-03D Rd-03E Rd-04 01 Kit 24G 10G Radarsensor Bewegung des menschlichen Körpers Präzision Rang Positionierung Gestenerkennung

4,90 €

inkl. 19 % MwSt. auf die Ware; bestätigter Versand nach Deutschland enthalten

Variante auswählen

Lieferung nach Deutschland
Lieferzeit: 22–25 Tage

Angezeigter Planpreis. Bestellungen sind noch nicht freigeschaltet.

Produktbeschreibung

Rd-03E is a radar module equipped with Silicon Microelectronics' S3KM111L chip. The S3KM111L is an integrated microcontroller millimeter wave sensor SoC based on FMCW radar transceiver technology that operates in the 24 GHz K-band with a modulation bandwidth of up to 1 GHz per single frequency scan. This module uses the FMCW waveform and S3 series chip's proprietary advanced signal processing technology, combined with the MCU's proprietary radar signal processing and built-in intelligent presence sensing algorithm, to achieve accurate human body sensing ranging and gesture recognition. Developers can display distance information and gesture information in real time through the host computer tool.
The Rd-03E module can detect and identify moving and micro-moving human bodies, and report real-time distances. It can detect targets and gestures in designated areas and report results in real time. It is widely used in various AloT scenarios. This module has the characteristics of strong real-time performance, high ranging accuracy, large ranging range, and flexible configuration of algorithm parameters.
Rd-03E gesture recognition firmware mainly refers to recognizing the up and down movements of hands, and is mainly used in scenarios such as opening the lid/opening the toilet seat of smart toilets. It doesn't mean recognizing gestures such as "OK", "Yeah" and "Good".
Notice
1. The positive and negative directions are azimuth angles, and the up and down directions are pitch angles. 2. Accurate ranging detection range azimuth angle ±20°, pitch angle ±45° 3. The angular range of moving human body recognition is direction angle ±20°, pitch angle ±45°, and detection range is 0.3m~6m. 4. The angular range of micro-motion human body detection is direction angle ±20°, pitch angle ±45°, and the detection range is 0.3m~3.5m. 5. The motion recognition detection range has a direction angle of ±20°, a pitch angle of ±40°, and a detection distance range of 0.3~2.2m in a sector area. 6. Gesture recognition and micro-motion body examination range direction angle ±30°, pitch angle ±40°, detection distance range 0.5~1m sector area
