1-50PCS TP4056 18650 Lithium-Batterie Ladegerät Modul Typ-C/Micro/Mini USB 5V 1A Lade Board mit Schutz Dual Funktionen 1A

Produktbeschreibung

TP4056 Lithium Battery Charger Module 1A Portable Battery Charger Panel Type C Micro USB 4.5V-5V for Lithium Batteries
Feature
1. Wide Input Voltage Range: Our lithium battery charger module is compatible with a wide range of input voltages from 4.5V to 5V, making it versatile and adaptable to a variety of different power sources.
2. High Charging Current: The battery charging board can charge at a maximum current of 1000mA, meaning your batteries will charge quickly and efficiently.
3. Over-Discharge Protection: With over-discharge protection at 2.5V/3A, this battery charging module protects your batteries from damage due to over-discharging.
4. Compact Size: The small size of the board, measuring only 28*17*4mm, makes this mini battery charger board easy to install and use in a range of different settings.
5. Multiple Protection Features: This portable battery charger panel features both charging and over-discharge protection, preventing damage to your batteries from over-charging or over-discharging. Additionally, the module automatically controls the charging current, providing optimal protection to your batteries while charging.
Specification
Certification: NONE
Origin: Mainland China
Accessory Type: Battery Accessories
Model Number: Lithium Battery Charger Module
Type(optional): 1pcs;5pcs;10pcs
Input voltage: 4.5V-5V
Maximum charging current: 1000Ma
Charging cut-off voltage: 4.2V±1%
Battery over discharge protection voltage: 2.5V/3A
Board size: 28 x 17 x 4mm/1.10 x 0.67 x 0.16inch
Usage
Type-c female socket and the + - pad next to the power input, access the 5V input voltage. b+ connects to the positive terminal of the lithium battery, b- connects to the negative terminal of the lithium battery. out+ out- connects to the load, such as the booster board. Connect the battery to B+ B-, plug in the phone charger to USB, the blue light is on, indicating that there is power access, the red light is flashing, indicating that it is charging. When it is fully charged, the red light will stop flashing and become constant. You can connect a load to the OUT+ OUT- terminal, when the load is connected, the red light is always on. When there is power at the input, current is obtained from the power output, if no power is connected, current is obtained from the battery and the output is automatically switched off when the battery voltage is below 2.5V.

Produktdetails in Bildern

Produkteigenschaften

Markenname

NONE

Ursprung

CN (Herkunft)

Hochbetriebenes Chemikalienunternehmen

Keine

Zustand

Neu

Typ

Modul

Certification

NONE

Accessory Type

Battery Accessories

Type(optional)

1pcs;5pcs;10pcs

Input voltage

4.5V-5V

Maximum charging current

1000Ma

Charging cut-off voltage

4.2V±1%

Battery

2.5V/3A

Feature 1

18650 Battery

Feature 2

Electronic Kit

Feature 3

Diy Electronic Kit

Feature 4

Bluetooth Module

Feature 5

Type-c/Micro/Mini USB

Feature 6

TP4056 Lithium Battery

Feature 7

Charging Board

Feature 8

With Protection Dual Functions
