5–50 Stück IR2113S SOP-16 IR2113STRPBF IR 2113S 600 V MOS Grid High And Low Side Drive Chip IC

Produktbeschreibung

5-50pcs IR2113S SOP-16 IR2113STRPBF IR 2113S 600V MOS Grid HIGH AND LOW SIDE Drive Chip IC
Features
� Floating channel designed for bootstrap operation
Fully operational to +500V or +600V
Tolerant to negative transient voltage
dV/dt immune
� Gate drive supply range from 10 to 20V
� Undervoltage lockout for both channels
� 3.3V logic compatible
Separate logic supply range from 3.3V to 20V
Logic and power ground ±5V offset
� CMOS Schmitt-triggered inputs with pull-down
� Cycle by cycle edge-triggered shutdown logic
� Matched propagation delay for both channels
� Outputs in phase with inputs
Description
The IR2110/IR2113 are high voltage, high speed power MOSFET and
IGBT drivers with independent high and low side referenced output channels. Proprietary HVIC and latch immune CMOS technologies enable
ruggedized monolithic construction. Logic inputs are compatible with
standard CMOS or LSTTL output, down to 3.3V logic. The output

Produktdetails in Bildern

Produkteigenschaften

Markenname

NONE

Ursprung

CN (Herkunft)

Hochbetriebenes Chemikalienunternehmen

Keine

Zustand

Neu

Typ

SPANNUNGSREGELER

Versorgungsspannung

3.3V-20V

Betriebstemperatur

40+125

Paket

SOP

catalogue

Grid drive chip

Driver configuration

half-bridge

loadtype

MOSFET GBT

Number of drive channels

2

Peak filling current

2A

Peak pull current

2A

risetime

25ns

fall time

17ns
