20A MPPT Solar Laderegler 12/24V Batterie Max PV Eingang 60V Mit MC Solar Panel Anschluss EPEVER Regler Tracer2206AN

Produktbeschreibung

20A MPPT Solar Charge Controller Battery 12V/24V DC Input Max PV 60V Input EPEVER Solar Regulator With MC Connector
Overview
Tracer-AN (10A-40A) series charge controller adopts MPPT (Maximum Power Point Tracking) technology. In any situation, it can track the maximum power point (MPP) of the solar array and obtain the maximum solar energy rapidly and accurately. It can generate up to 30% more power compared with the PWM charge controller. This series can accept max.100V Voc and work with the solar panels which are designed for on-grid applications. The multifunction LCD display the system status vivdly.
MPPT tracking efficiency above 99.5%
Maximum charge conversion efficiency as high as 98%
Support lead-acid and lithium-ion batteries
Multiple load work modes
Charging power and current limitation function
High-temperature charging power derating function
Standard Modbus communication protocol with RS485 interface
Real-time energy statistics function
Model
Tracer2206AN
Nominal system voltage
12/24VDC/Auto
Battery type
Lead-acid(Sealed/Gel/Flooded)/Lithium(LiFePO4/Li(NiCoMN)O2)/User
Battery input voltage range
8~32V
Rated charge current

Produktdetails in Bildern

Produkteigenschaften

Brand Name

EPever

Hign-concerned Chemical

Keine

Origin

CN (Herkunft)

Model Number

Tracer2206AN

Maximum Current

20A

Certification

CE

Certification

FCC

Certification

RoHS-Konformität

Is Smart Device

Ja
