3S/4S/5S BMS 12V 16,8V 21V 100A LiFePO4 Ternäre Lithium-Batterie Schutz Platine Li-polymer Balance Lade Modul

Produktbeschreibung

Parameter
Pin mode
P-: negative pole of load C-: negative pole of charger B-: negative pole of battery
Hands-on guide
Output current: separate port 80A; same port 60A
Note: Lithium batteries should be charged with a special charger for lithium batteries. Do not use lead-acid battery chargers. Lead-acid charging may cause high voltage to break down the MOS tube of the protection board, causing the protection board to be overcharged and not protected.
3-series sub-port wiring method (refer to the 3-series sub-port wiring diagram)
��Connect the 3 battery packs in series according to the battery connection method in the 3-series split port wiring diagram.
��Connect the negative pole of the charger to C- of the protection board, and the negative pole of the load to P-.
��Connect the positive pole of the charger and the load to the positive pole of the 3-series battery.
��Refer to the 3-series split port wiring diagram and connect the positive poles of the 3 battery packs to B+, B4, and B3 in sequence with 3 wires.
��Connect the negative poles of the 3 strings of batteries to B-. B1, B2 and B- are shorted.
��After all the wires are connected according to the 3-series sub-port wiring diagram, check whether they are correct, and then start to use after confirming that they are correct.
��During use, when the indicator light on the protection board is on, it means that the corresponding battery pack is in a balanced working state (that is, the battery is unbalanced at this time).
