SONGXIN DC 3V-6V Bis 400kV 400000 V Boost Step Up Power Module Hochspannungsgenerator

Produktbeschreibung

Description
Report Item
New DC 3V-6V Bis 400kV 400000V Boost Step Up Power Module High Voltage Generator
input voltage: DC 3 V to 6 V
Input current: 2 A - 5 A
High pressure type: the type of pulse current
Output voltage: 400000 v(Please pay attention to safety)
High pressure discharge distance between: 10 mm - 20 mm
The output high voltage wire length: 100 mm
Input power cord length: 100 mm (the red line is positive)
Wiring
Red and green power connection red line:"+" green line "-"
output: the other side,same color cable
please notice
the high-voltage module should avoid the use of electricity in high voltage no-load. (Power must be adjusted to a suitable distance to the high-voltage output line, battery capacity is proportional to the distance and the use of the high-pressure arc ( not a voltage as high as possible, you must provide enough current ). Experimental test of the arc distance from short to long, Do not exceed the maximum arc distance electricity, energy can not be released due to high pressure, can easily damage the module. )
Work: intermittent, continuous work does not allow more than 1 minute and the output side does not allow shorting. Improper voltage and long working hours easily damaged module

Produktdetails in Bildern

Produkteigenschaften

Markenname

XIASONGXIN LIGHT

Ursprung

CN (Herkunft)

Hochbetriebenes Chemikalienunternehmen

Keine

Zustand

Neu

Typ

SPANNUNGSREGELER
