TZT Timer Switch Controller Board 10S-24H Einstellbare Verzögerung Relais Modul Für Verzögerung Schalter/Timer/Timing Lampe

Produktbeschreibung

Function descriptor
1. Power-on reset automatically
2. The delay time adjustment range of about 10 seconds to 24 hours
3. Current output voltage ratio parameter:3V/300mA;5V/200mA;9V/100mA
4. Input voltage:3.3-18V
5. It can drive 3V/5V/12V relay/LED and so on.
6. Function:delay switch,timer,timer light etc.
7. Size:18.7mm*18,7mm*7.4mm pins distance:2.54mm
Set Timer
1.NOT short M Pads on PCB(0:Switch OFF;1 Switch ON)
00000:10 seconds 01000:4 minutes 10000:14 minutes 11000:30 minutes
00001:20 seconds 01001:5 minutes 10001:16 minutes 11001:35 minutes
00010:30 seconds 01010:6 minutes 10010:18 minutes 11010:40 minutes
00011:60 seconds 01011:7 minutes 10011:20 minutes 11011:45 minutes
00100:90 seconds 01100:8 minutes 10100:22 minutes 11100:50 minutes
00101:120 seconds 01101:9 minutes 10101:24 minutes 11101:55 minutes
00110:150 seconds 01110:10 minutes 10110:26 minutes 11110:60 minutes
00111:180 seconds 01111:12 minutes 10111:28 minutes 11111:75 minutes
00000:1.5 hours 01000:5.5 hours 10000:9.5 hours 11000:17 hours

Produkteigenschaften

Markenname

TZT

Ursprung

CN (Herkunft)

Hochbetriebenes Chemikalienunternehmen

Keine

Zustand

Neu

Typ

RELÄS

ist kundenspezifisch

Ja

Betriebstemperatur

40-+85

Anwendung

Computer

Paket

DIY KIT

Electronic products

For Arduino STM
