Trianglelab Filament-Endsensoren für 3D-Drucker – Materialerkennungsmodul für 1,75 mm Filament

28,90 €

inkl. 19 % MwSt. auf die Ware; bestätigter Versand nach Deutschland enthalten

Lieferung nach Deutschland
Lieferzeit: 8–12 Tage

Angezeigter Planpreis. Bestellungen sind noch nicht freigeschaltet.

Produktbeschreibung

***-***
This filament run out sensor unit is design for detect whether your printing is run out of filament.
During printing if the unit detected that there is out of filament it will send a signal to the main board.
With correct firmware settings the printing will paused untill the operator reload the filament and resume the printing.
It works with all available materials;flexible,clear,opaque,filled,etc.
The unit can handle as many filaments simultaneously.As soon as one of them will be missing,the unit will send a message to the next one,up to your main board.
Two screws are provided so you can install it where you want.
Works with almost any printer.
Durable injection modeling casing and industrial grade components.
Supply Voltage 3.3-5V
Operating Temperature below 80℃
Filament Diameter 1.75MM(1-2MM)
Filament Presence LOW
Filament Absent HIGH(equal to Supply Voltage)
Please install the unit after the spool and before your extruder.
Fix it on your printer and along with the path of filament is recommend.
Pay attention to the direction indicated by the arrow on the body.
Inserted the 4mm PTFE tube to both side of the unit for guiding the filament and help to reduce the friction.
Cable color
Red 3-5V
