BB Eckradius Schaftfräser R Bullnose CNC Wolframkarbid Stahlschneider Oberflächenbearbeitung Metallfräser Werkzeug 3 4 Nuten R0,5 R1

Produktbeschreibung

BB® Tungsten Carbide Corner Radius End Mills
Corner radius, uneasy to cracking, widely used in high speed cutting；
Corner radius to protect cutting edge.reduce fracturing during the milling process while greatly increasing tool life and enhancing finish.
Surface Machining & Inclined plane machining
Helix Angle:35 deg，high adaptability to the material and hardness of workpieces, widely used to mold and product processing and cost efficient.
BB2055 Series
Color: Copper Density: 14.5 g/cm3
Hardness: HRA 92 Grain Size: 0.6um
Bending Strength: 3000N/mm2
Raw material: Use ZK30UF with 10%Co content and 0.6um grain size.
Coating: TiSiN, with very high surface hardness and good wear resistance.
BL2060 Series
Nano-composite coating
Higher resistance to heat and wear.
35° helical angle.
Suitable for milling general steel under HRC 55, stainless steel, hardened steel, etc
It is not recommended to machining viscous metals and non-ferrous metals.
Machining example
End mill: 8R1*60
Material: 1.2344 die steel, hardened material, HRC50

Produktdetails in Bildern

Produkteigenschaften

Markenname

BB

Hochbetriebenes Chemikalienunternehmen

Keine

Ursprung

CN (Herkunft)

Modellnummer

Corner Radius

Grad

R0,5

Material

Karbid

Typ

Schaftfräser

Gesamtlänge

50 100 150

Durchmesser

1 4 6 8 10 20mm

Beschichtung

AlTiSiN

Schaft

Schlicht

Endprofil

Eckenradius Bullnose

Helix-Profil

Standard

Anwendung

Oberflächenbearbeitung Geneigte Flächenbearbeitung
