HD CCD Rückfahrkamera für Opel Astra H J Corsa Meriva Vectra Zafira für FIAT/Buick Regal für Mocha x 2012-2020

Produktbeschreibung

Using the south Korean PC1030 chip
Image Sensor: 1/3 " Color CMOS
Effective Pixels: PAL 512(H)X582(V); NTSC 512(H)X492(V)
Horizontal Resolution: 420 TVL
Minimum Illumination: 0.1Lux
Lens: 1.9mm
Lens Angle: 120 degree
Synchronization: Internal synchronization
Signal to noise ratio: >48db
Signal System: PAL / NTSC
Electronic Shutter: Auto
Video Output: RCA interface, 1.0Vp-p, 75Ohm
White Balance: Auto
Backlight Compensation: Auto
Power: DC 12V
How to use
Mount the camera at the back of the car (on the license plate back window or other suitable places)
Connect the power of the camera to your reverse lights - red wire to positive and black wire to negative.
Connect the video cable of the camera to the extension cord.
Connect the extension cord to your car monitor.

Produktdetails in Bildern

Produkteigenschaften

Markenname

OTERLEEK

Hochbetriebenes Chemikalienunternehmen

Keine

Ursprung

CN (Herkunft)

Leitlinie

Ja

Material

ABS

Linsenmaterial

Kunststoff + Glas

Schalenmaterial

Kunststoff

Kabelgebunden oder kabellos

Draht

Länge des Videokabels

6m

View Angle

130deg

TV System

PAL/NTSC

Resolution

480 TVL

Image Sensor

CCD
