Wanptek fonte de alimentação dc ajustável 30v 10a led banco de laboratório digital fonte de alimentação estabilizada interruptor regulador de tensão
Return&refund policy
Eligible items are covered by return and refund support. If the item does not arrive or is not as described, the buyer can request help.
Security & Privacy
Safe payments: We do not share your personal details with any third parties without your consent.
Secure personal details: We protect your privacy and keep your personal details safe and secure.
Oferta AI para o seu mercado
Seleção otimizada com base na categoria, rota de envio, velocidade de entrega e popularidade no seu mercado.
Por que este produto combina com o seu mercado
- • Entrega estimada: 7.
- • Forte sinal dos clientes: 4.9★ de 51 avaliações.
- • As recomendações focam nesta categoria e na disponibilidade para o seu mercado.
Product specifications
Descrição detalhada do produto
This product is shown with available options, market-specific pricing and verified specifications.
- Brand: wanptek
- Sales: 59
- Package size: 10 × 10 × 10 cm
- Package weight: 1.55 kg
- Rating: 4.9 / 5
Before adding to cart, choose an available option and check the quantity.
Wanptek's new series products. This model is a miniature switching DC power supply. The output voltage and current can be controlled and adjusted by variable resistors respectively, so it provides more convenience and accuracy in the adjustment of voltage and current. The panel also provides high-precision two/three-window digital tube display of voltage, current and power, so that users can intuitively see the current use status and various parameters of the machine
1.Small size, light weight and high power density.
2.Constant pressure and constant current switch automatically.
3.LED display of voltage, current and power, high precision and features of voltage stabilization, current limiting, and simple operation.
4.Adjustable Output Voltage & Current: output voltage and output current can be continuously 5.adjusted between 0 and nominal value with fine regulating and coarse regulating
6.it has over voltage protection(OVP), over current protection(OCP), over temperature protection
7.Temperature controlled fan cooling, low noise, long life.
8.Dual voltage input and convenient choice.
9.Output Voltage ranges from 0 to rating voltage with continuous adjustment.
10.Output current ranges from 0 to rating current with continuous adjustment
11. NPS power supplies is
Resistance adjustment
12.
APS3010H
and
APS605H
power supplies have
three groups of memory functions
voltage and current encoder adjustments.
13.
WPS3010H
WPS605H
DPS3010U
DPS605U
GC3010H
GA3010H
14.
AC 110V and 220V
can work
rest assured to choose.
Output Power
300W
Output voltage
0~30V/60V
Output current
0~10A/5A
working environment
input voltage：AC 230V/115V±10%；50Hz/60Hz
Working temperature：0℃～40℃;relative humidity
Storage temperature：-10℃～70℃;relative humidity
Constant voltage CV
Voltage stability：0.1%±3mV
Load stability： 0.2%±3mV
Ripple voltage：≤0.5% Vp-p
0 to rated voltage continuously adjustable
constant current CC
Current stability：0.1%±3mA
Load stability： 0.2%±3mA
Ripple current：≤0.5% Vp-p
Recovery time：≤500μS
Temperature coefficient：≤100ppm/℃
0 to rated current continuously adjustable
display
LED digit display
Display accuracy：0.5%±digits
Display resolution： voltage 0.1V/0.01V， current 0.01A/0.001A
1. Production line test.
(24hours Working)
3. Product aging, electroplating,such as resistors, capacitors, relays, DC motors, LEDs, etc.
4. Charge the battery.(Include car battery)
6. All other occasions requiring DC power supply.
1x DC power supply
1x power cord (EU,US,UK,AU)
1x Test line（gift）
1x Instructions
Q: Is the input voltage of the power supply 220V or 110V?
A: Yes.
Q: Does this power supply charge the battery of a 25v car?
A: You can charge a 25V battery, because the maximum voltage of the power supply can reach 30V (note！！the power supply Set up voltage must be greater than the battery voltage before it can charge it, otherwise it will kick back the power supply and damage the power supply!)
Q: Can it be used for electroplating and anodizing?
A: It can be electroplated and anodizing
Q: When does the fan rotate?
A: When the internal temperature of the power supply is greater than 50℃, it will start automatically.
Q: When this power is turned off and on again, does it remember the last setting?
A: It is controlled by the adjustment knob, and as long as you don't move the adjustment knob, it will power on at the previous setting.
OCP Short Circuit Alarm
When a short circuit occurs, the variable DC power supply will stop output and send out an alarm to remind you.
