Zigbee 3.0 USB Dongle Plus EFR32MG21 Universal Open Source Hub Gateway Works with Home Assistant openHAB Zigbee2MQTT ZHA NCP
If you encounter some problems in the use of the forum, you can go to the exchange, which has the answers you want.
SZKOSTON dongle plus has a wide range of supported devices, such as ZBMINI-L, SNZB01, SNZB02, SNZB03, SNZB04, S26R2ZB, S40 LITE ZB. Dongle Plus is pre-flashed with coordinator firmware, you can also flash router firmware to extend the network range.
SZKOSTON Dongle Plus support a variety of common systems, like Linux, Ubuntu, Raspbian, Windows, macOS (Windows and macOS require corresponding driver installation).
If the device is following Zigbee standards it is possible it will work with other gateway solutions, it is just not confirmed as working yet!
1、Pre-flashed with EZSP v8 (EmberZNet Serial Protocol version 8)
2、Can use ZHA in Home Assistant or Zigbee2MQTT (pre-alpha)
3、Base on EFR32MG21+CH340E
4、+20dBm output gain，PCB antenna
5、Plastic Shell
6、Support OTA Via Uart (Press the BOOT button,then press and release the nRST button, fiannaly release the BOOT button)
7、Baud rate ：115200
It comes pre-flashed with an unsigned EmberZNet 6.7.9 Zigbee NCP application firmware with Silabs standard EZSP v8 (EmberZNet Serial Protocol version 8) interface enabled as well as the standard Silabs Gecko Bootloader firmware for recovery, meaning it can be used either as-is out-of-the-box or flashed with custom application firmware via USB.
Hardware is at its core based onSilicon Labs EFR32MG21 Series 2 Multiprotocol Wireless SoC(part numberEFR32MG21A020F768IM32) and aWCH CH340E USB to Serial/UART Bridge Controller. While it only has a PCB circuit board antenna the radio has an integrated +20 dBm Power Amplifier (output power) and -104.5 dBm Receive Sensitivity which should be made for a very good Zigbee coordinator or Zigbee router if both hardware and firmware were properly implemented.
