2X14MM Reed Switch Magnetic Switch Normally Open Magnetic Induction Switch 2*14mm
Return&refund policy
Eligible items are covered by return and refund support. If the item does not arrive or is not as described, the buyer can request help.
Security & Privacy
Safe payments: We do not share your personal details with any third parties without your consent.
Secure personal details: We protect your privacy and keep your personal details safe and secure.
AI offer for your market
A curated pick based on category, shipping route, delivery speed and popularity in your selected market.
Why this product fits your market
- • Estimated delivery: 7.
- • Strong customer signal: 4.9★ from 18 reviews.
- • Recommendations focus on this product category and your market availability.
Product specifications
Product detail photos
Detailed product description
This product is shown with available options, market-specific pricing and verified specifications.
- Brand: DQLZV
- Sales: 91
- Package size: 12 × 12 × 5 cm
- Package weight: 0.01 kg
- Rating: 4.9 / 5
Before adding to cart, choose an available option and check the quantity.
PRODUCT 2x14mm
INTRODUCTION
Reed is a shortname for dry reed, which is a passive electronic switch element with contacts. It has the advantages of simple structure, small volume and control. Its shell is generally a sealed glass tube, which is equipped with two iron elastic reed plates and is filled with inert gas called rhodium. Usually, two reed pieces made of special materials in glass tube are separated. When the magnetic material is close to the
SPECIFICATION AND PARAMETER
Glass Length
14mm
Glass Diameter
2mm
Total Length
45mm
Max. Switching Voltage
300VDC
Min.Breakdown Voltage
150VDC
10W
Max. Switching Current
0.55A
Max. Operate time
0.45ms
Bounce time
0.25ms
Max. Release time
0.35ms
Resonant Frequency
5000HZ
Max. Operating
400HZ
Pull in Value
20-70AT
7AT 7T
